System 73 65 799 00
=> €/$

12 Volts generator / electronic ignition for 1 Zylinder JAWA  and CZ bikes

JAWA 11/353/355/356/559/590; CZ 450/453/455/470/475/477/482/485/487

The 12 Volts system supports the charge control light (6 Volts system 73 65 799 6V doesn't)!

Magnet based generator with integrated fully electronic ignition. Output 12V/100W DC. Solid state ignition with own power supply from within the system. Replaces stock dynamo, points, condenser, ignition coils. You may drive without a battery if you want. There is no need for changes on engine casing.

This system is alternative to our systems 353 61 799 and 450 61 799. The system is easier because it has no external sensor.

Please note that this is a negative earth system
Advantage over original system
  • all parts are new
  • more light output
  • very stable ignition with solid spark
  • better starting, better fuel burning
  • no huzzle anymore with setting points
Documentation
Photos
